The set voltage, frequency modulation control (control), and protection functions of the(frequency conversion) series resonance testing equipment (also known as variable frequency series resonance)are integrated as a whole, eliminating the need for bulky regulators and providing easy operation and intuitive readings. Due to the high Q value of the information system (30-120), the constraints on on-site testing caused by the insufficient capacity of the working power supply market have been effectively addressed.

Test wiring and procedure forfrequency conversion series resonance test device

Procedure for experimental operation

1. Follow various test wiring methods to ensure good contact at each point, ensure that one point is grounded and located closest to the voltage divider .

2. Ensure that the power connection is correct.

3. Turning on the power control switch of the host system will display the main menu

4. Move the cursor to: Test parameter settings; Press the confirm button. Modify various parameters using the up, down, left, right, and confirm keys. Then return to the main menu.

5. Move the cursor to: System parameter settings: Press the confirm button. Modify the time parameters using the up, down, left, right, and confirm keys.

6. Move the cursor to: Enter Test: Press Enter.

7. Voltage can be selected through experimental research methods, and the test sample can be tested using the confirm button.

8. To choose manual testing, first find the resonance point of the test sample and use the up and down keys to make the test voltage at the highest point; After this operation is completed, press the panel voltage key to shift with the left and right keys. Press the up key to increase the excitation power (referring to the work done by the object in a unit time). When it approaches the test voltage, slowly increase the power (referring to the work done by the object in a unit time) to prevent breakdown. After setting the rated voltage, it will automatically test on the host When you choose automatic testing, simply press the enter key and do not perform these tasks.

9. Before entering the experiment, pay attention to the safe working distance of the test sample to ensure the safety of one's own life.

10. Please do not make arbitrary changes to the TestMeasure operation item in the main menu to prevent loss.
